Discover the Ultimate Sound Experience

Transcend Push Pull

Elevate your audio with our meticulously crafted amplifier, designed for audiophiles seeking unparalleled sound quality.

Product Description

Unmatched Craftsmanship and Sound Quality

My re-design of this popular amplifier incorporates better coupling capacitors, improved output transformers, a dead silent toroidal power transformer, and more power, finesse, and smoothness over the original! Fewer and higher-end components provide a transparent 3D soundstage and “meat on the bones” midrange that only SET designs are known for.

I’ve designed this amplifier exclusively to provide more power than a traditional SET amplifier while preserving the rich harmonics that they’re known for! The venerable 6SN7 is used as both the driver and phase splitters while using only two coupling capacitors per channel and cathode auto-bias to the output tubes. It runs exclusively in Class “A” and offers both Ultra-Linear Mode/ Triode-Mode operation with variable damping. This amplifier is an exception to the typical “push-pull” signature sound and does not sound strident or bright in any way; it has warmth, dynamics, and excellent spatial qualities!

For Purchase Inquiries Please Use the Contact Form

$5475.00

Key Features

Transcend Push Pull

  • Class “A” Push-Pull operation- Cathode “Auto-Bias” requires no adjustments and prevents Bias failure issues- 6SN7 input direct-coupled to 6SN7 LTP phase splitter
  • Toroid power transformer for low EMI
  • ALPS input and feedback potentiometers
  • Dual chokes in the power supply provide excellent noise performance
  • Ceramic tube sockets with gold-plated pins
  • Audyn True Copper signal coupling capacitors
  • Minimal signal path and less gain stages for increased transparency
  • Triode/UL mode (switchable)- Continuously variable negative feedback loop for optimum speaker matching-

Download the Manual

Questions About This Amp?

Technical Specifications

Our amps feature the latest in audio technology, including:

  • 4 and 8 ohm outputs (16 ohm available upon request)
  • Integrated volume control to be driven directly from a source (volume can be omitted by request)
  • EL34- triode-mode= 20 watts/U.L. mode=35 watts
  • KT88- triode-mode= 25 watts/U.L. mode=45 watts
  • KT120- triode-mode= 40 watts/U.L. mode=55 watts
  • KT150- triode-mode= 45 watts/U.L. mode=65 watts
  • Ships with Tung Sol 6SN7’s and Svetlana EL34 (stock).- EL34, KT120 or KT150 available upon request
  • Dimensions-18.5″ wide x 14.5″ deep x 8″ tall- weight (unboxed): 45 lbs.
  • 2-year parts and labor warranty-

Experience the Pinnacle of Sound

Don’t miss out on the opportunity to elevate your audio experience with our premium hand-built amplifiers. Crafted with precision and passion, our products deliver unparalleled sound quality. Take the next step towards audio excellence today.
